1） Forging crane wheel spec. type

Double flange wheel Type A	Single flange wheel Type B	Without flange wheel Type C

2） Port Track Driving Forged Crane Wheel description

1.Forging Crane wheel form : single flange wheel , double flange wheel , without flange wheel

2.Crane wheel of size available : OD 250mm-950mm

3.Forging crane wheel material: high strength alloy steel , such as :42CrMo ;40CrNi2Mo, 65Mn (SWQR-1 ); 60 and so on or according customer request for Crane wheel .

4. crane wheel tread surface and flange heat treatment HB300-380 , hardness depth more than 10mm .

Basic Specification										Basic Specification
D	D1	B	B1	d	B2 max	C min	b min	X max	Y max	S	d1	d2	D2	D3	R	r
mm								μm		mm
250	280	90	90	70	40	5	20	50		25	120	30	210	165	10	5
315	355	110	110	110	60	5	20	60		30	175	30	265	220
		155		120	80	12.5	25				190		255
400	440	125	140	120	70	7.5	20			35	190	35	340	265
	450	155		130	80	12.5	25				205		330
500	540	130	140	130	70	10	20			40	205	40	430	315	20
														320
	550	175		140	100	12.5	25				220			325
630	680	145	160	160	70	12.5	25	80		45	255	50	560	405
		175			100
		210	190	180	120	15	30			60	285		530
710	760	155	180	170	80	12.5	25			50	270	55	630	450	25	6
		195			120
		210	210	190		15	30			65	300		600
800	850	155	180	180	80	12.5	25			50	285	60	710	500
		195			120
